Product Description
Overview:
110V Control Board is specially designed for Aqua-X Irrigation Control System. It features 6 individually-controlled 110V outputs for the pump control in the Aqua-X Control System.
Features:
- LED Power Indicator
- Addressing Button
- 6 Individually-Controlled 110V Outputs
- Individual LED Indicator for Each Output
- Double RJ12 Cable Sockets for Easy Connectivity
Package Contents:
- 1 x 110V Control Board
- 1 x 16ft RJ12 Cable
Specifications:
| Input Voltage: | 120 VAC |
| Max Input Current: | 9A |
| Max Output Voltage/Current: | 120VAC/1.5A per Output |
| Working Environments: | Temperature 32°-122°F, Humidity≤90% |
| Packaging Dimensions: | 275mm(L) x 164mm(W) x 62mm(H) |
